Create Paths



+PATH

Create Paths

Creates path from centerline


INPUTS

  • centerline : Centerline of the path in plan in 2D

  • width : Width of path. Default >> 10.0ft

  • bottoms : Points describing the bottom-center point of each path - will snap to closest centerline

  • slope : Percent slope of the path. Default = 5

OUTPUTS

  • <P> : Path instance
